12INSTRUCTIONSFORTHEDISASSEMBLY/ASSEMBLYOFTHECLUTCH
ATTENTION:
The following operations can be performed by a skilled mechanic under the
conditionstohaveavailablethededicatedtoolsshown onthetext,otherwiseitis
necessarytoapplytoanAuthorizedServiceCenter.
Refertothefollowingdrawingduringtheoperations.
OPERATIONS TOOLS
Clutchdisassembly
1. Removetheclutchcover(3screwsM6). § Allenwrench5mmTtype
2. Removethesparkplugandreplacewithspecialtool
topreventcrankshaftfromturning.
§ Pistonfitting:P.N.10271
3. Removenut(1nutM10). § 12pointwrench17mm
4. Removetheexternalwasher,thedrumwithroller
bearing.
5. Removethespecialtoolfromtheheadandusingthe
clutchwrench,removethe16x1nutandthecone
safetywasher.
ATTENTION:
Turnclockwiseasnuthasleftthread
§ Clutchwrench:P.N.10270
§ 24mmsocket
6. Applyclutchpulleronclutchandremoveclutchwith
12pointwrench19mm.
§ Clutchpuller:P.N.B55614C
§ 12pointwrench19mm.
7. Removekeyfromshaft
8. Removethestarterring(3vitiM6) § 12pointwrench10mm
1
2
3
4
5
6
7
8
9
10
A
A
A
1Drumnut5Sprocket9Conesafetywasher
2Externalwasher 6Clutchdrum10Clutchbody
3Rollercage7Internalwasher11Starterring
4Screw8Lockingnut 12Screw
