IAME Parilla Leopard TaG Series - Engine Preparation and Installation on Chassis; Installation Sketch

MAN048ING5
3 PREPARATIONANDINSTALLATIONOFTHEENGINEONTHECHASSIS
NOTE:
Incasetheengineissuppliedalreadyassembledonthechassis,itisatcareofthe assemblerto
follow these instructions. The final customer, in this case, can skip this section and can start
readingfromsection4.
Whenevertheengineoracomponentisdisassembled,itisnecessarytoalwaysfollowtheunder
showninstructionsforproperreassembly.
3.1 INSTALLATIONSKETCHOFTHEENGINEONTHECHASSIS
