Issue 1.11
45
10 Technical data
10.1 Main data
Short description
Name ibaBM-DDCS
Description Bus monitor for DDCS drive bus
Order number 13.120710
DDCS interface
Number 3 for one DDCS drive bus
Design 2 HBFR Versatile Link connector (1 mm POF) for RX and
TX, simplex, duplex, without interlocking (per link)
Typical application Link0: Connected with control (only Rx is used here)
Link1: Connected with measurement interface of the drives
Link2: Connected to computer with DriveWindow for
configuration and measurement, if required
ibaNet interface
Number 1 (e.g. connection to ibaPDA)
ibaNet protocol 32Mbit Flex
Data transmission rate 32 Mbit/s
Sampling rate Up to 40 kHz, freely adjustable
Connection type 2 ST connector (62.5 µm / 125 µm), cable length up to
2000 m without repeater
Power supply, operating and indicating elements
Power supply +24 V DC (±10 %)
Power consumption Up to 15 W
Rotary switch Device address (in a cascade)
Indicators 4 LEDs for the operating status
8 LEDs for the channel status
Operating and environmental conditions
Cooling Passive
Operating temperature 32 °F to 122 °F (0° C to 50° C)
Storage and transportation temperature -13 °F to 158 °F (-25° C to 70° C)
Humidity class according to DIN 40040 F, no condensation
Protection class IP20
Mounting DIN rail , vertical
Standards EMC: IEC 61326-1
FCC part 15 class A
