IBC CX Series

Boiler part diagrams - CX 150, CX 199
Item Description P-kit # Qty
1 Top access cover - CX 150 1
Top access cover - CX199 1
2 Exhaust duct 1
3 Intake duct 1
4 Temperature sensor P-361 1
5 Safety Ignition Module plus (SIM+) P-271B 1
6 Front door cover - CX 150 1
Front door cover - CX 199 1
7 Thumb screw 2
8 Terminal block cover 1
9 V-10 touchscreen controller 1
10 Transformer P-9059 1
118
