IBC EX Series - Service and Maintenance; General Maintenance Schedule

6.5 Cleaning a condensate trap
Condensate traps should be checked every two months, cleaned
and refilled as necessary. Before cleaning the condensate trap,
you must turn off the power to the boiler, and allow it to cool down.
Important: Installers or service contractors should ensure that the
end user is instructed on cleaning and refilling the trap.
Warning
If condensate neutralization is used, check the pH
level of condensate discharge.
Never operate the boiler unless the trap is filled with
water. Failure to comply will result in severe personal
injury or death.
1.
Unscrew the union nut.
2.
Rotate the elbow sideways, so that you
can remove the condensate trap base.
77
6.5 Cleaning a condensate trap
