INSTALLATION AND OPERATING INSTRUCTIONS
HC SERIES BOILERS HC 13-50, HC 23-84, HC 29-106, HC 20-125, HC 33-160
SPECIFICATION HC 13-50 HC 23-84 HC 29-106 HC 20-125 HC 33-160
CSA Input (Natural Gas or Propane) – MBH 13.5 - 51 23 - 84 28.5 - 106 20 - 125 33 - 160
CSA Input (Natural Gas or Propane) – KW 3.95 - 14.94 6.7 - 24.9 8.4 - 31.0 5.6 - 36.6 9.7 - 46.9
CSA Output – MBH 12.4 - 45.4 21.2 - 74.8 26.3 - 94.3 18.6 - 110.8 30.4 - 140.0
CSA Output - KW 3.64 - 13.3 6.2 - 21.9 7.7 - 27.6 5.4 - 32.5 8.9 - 41.0
A.F.U.E 94% 94% 94% 95% 94%
Min Gas Pressure (Nat. Gas or Propane) – inch
w.c.
5 5 5 5 5
Max Gas Pressure (Nat. Gas or Propane) – inch
w.c.
14 14 14 14 14
Power (120Vac/60Hz) - Watts @ full re with
internal pump
126 126 128 130 164
Weight (empty) – lbs/Kg 85 / 39 85 / 39 85 / 39 85 / 39 85 / 39
Pressure Vessel water content – USG/Liters 0.37 / 1.4 0.37 / 1.4 0.37 / 1.4 0.5 / 1.9 0.5 / 1.9
Max boiler ow rate - USgpm 9 9 10 11 11
Min boiler ow rate - USgpm 2 2 3 3 3
Max Operating Pressure – Space Heating Coil
- psig
43.5 43.5 43.5 43.5 43.5
Approved installation altitude - ASL 12,000 ft 12,000 ft 12,000 ft 12,000 ft 12,000 ft
Ambient Temperature – Low (°F/°C) 32 / 0 32 / 0 32 / 0 32 / 0 32 / 0
Ambient Temperature – High (°F/°C) 122 / 50 122 / 50 122 / 50 122 / 50 122 / 50
Max relative humidity (non-condensing) 90% 90% 90% 90% 90%
Min water Temperature - Space Heating (°F/°C) 50 / 10 50 / 10 50 / 10 50 / 10 50 / 10
Max water Temperature – Space Heating (°F/°C) 194 / 90 194 / 90 194 / 90 194 / 90 194 / 90
Max equivalent vent length 3" (each side) 120' 120' 120' 120' 120'
Max equivalent vent length 2" (each side) 35' 35' 35' 35' 35'
* Natural Gas boilers require a Propane conversion kit (see page #3-2, Table 9) to be ordered separately if converting a Natural Gas boiler to Propane. Propane (LP)
boilers require a Natural Gas conversion kit (see page #3-2, Table 9) to be ordered separately if converting a Propane boiler to Natural Gas.
† boilers are shipped with 30 psig pressure relief valve
SPECIFICATIONS

IBC HC Series Specifications

General

Heat Exchanger Material	Stainless Steel
Installation Type	Wall-mounted
Type	Condensing
Fuel Type	Natural Gas or Propane
Efficiency	Up to 95%
Ignition Type	Electronic
Vent Diameter	2 - 3 inches
Dimensions	Varies by model
