INSTALLATION AND OPERATION INSTRUCTIONS
1-16
SL 10-85 G3, SL 14-115 G3, SL 20-160 G3, SL 30-199 G3 MODULATING GAS BOILERSSL 10-85 G3, SL 14-115 G3, SL 20-160 G3, SL 30-199 G3 MODULATING GAS BOILERS
1.4.9 Combustion Air Filtration
If combustion air contamination from ingested particulate matter is a concern in any
installation, an optional air intake lter may be installed. IBC supplied air intake lters
have a known pressure drop and fouling factor and should be used as a component of the
combustion air system according to the allowable intake length in Table 4.
IMPORTANT: Under no circumstances should a third-party air lter be installed on
an IBC boiler without proper evaluation and written approval of the IBC Engineering
Department.
1.4.10 Closet Installations
For installations in a conned space (such as a closet), ventilation openings may be
needed through a door or wall to prevent excessive heat from building up inside the
space.
The boiler shall not be exposed to ambient conditions above 122°F (50°C) or below 32°F
(0°C).
NOTE
Combustion fan blockages
can occur when environmental
particulate and foreign matter
contaminants (leaves, dust,
dandelion & cottonwood uff,
etc) are drawn into the air intake.
In areas where this problem is
suspected to be an issue, our
optional air intake lter should be
installed.
Filters should be checked and
cleaned or replaced on a regular
schedule based on the severity
of the problem.
Figure 21: Direct vent - intake, exhaust system with optional air intake lter (ltration may
also be used on indoor air applications as required)
