IBC SL 10-85 G3

1.
Remove the boiler door.
2.
To remove the condensate retainer,
undo the two wing nuts, and put aside.
3.
Fill the condensate trap with water, and
ensure that the bottom union cap is
hand-tightened to prevent leakage.
4.
Loosen the upper union nut, and
slide the trap over the boiler drain
outlet, and then tighten the upper
union nut.
38
Section: Installation
