Page #13 background imageLoading...
Page #13 background image
Connection specifications
The following table displays the required connection specifications.
SL 26-260 G3 SL 40-399 G3
A Flue Outlet 3" Schedule 40 4" Schedule 40
B Combustion Air Inlet 3" Schedule 40 4" Schedule 40
C Safety Relief Valve and Air
Vent
¾" NPT - F
D LCD Display 2¼" x 4"
E Water Outlet 1½” NPT-M
F Water Inlet 1½” NPT-M
G Knock-outs (8) ½"
H Gas Inlet ¾" NPT-F
I Condensate Outlet ¾" Hose
Table 2 Connections
9
