Parts/Test Point Locations 119
3.5-In Maxtor Hard Disk
3.5-In Maxtor Hard Disk Drive Jumper Settings
J50 Description
On Drive configured as a Master or
Drive configured as a Master, with an attached Slave
Off Drive configured as a Slave.
