136
1-6 20L2198 Assembly Lower Case (without SPS) X X
1-NS 02K2334 Screw for Power Supply, Bracket plate and
Top Cover
XX
1-NS 20L2206 Port Bracket Screw X X
1-NS 20L2207 Port Bracket Screw X X
1-7 20L2190 Power Switch Wire (switch + wire) + Hard
Drive LED Wire (LED + wire) + Power LED
Wire (LED + wire)
XX
1-8 36L9066 V72MA (Rage Pro, 8MB SGRAM, 512KB
Cache, Solo-1)
X
1-8 36L9056 V72MA (Rage Pro, 8MB SGRAM, 512KB
Cache, Solo-1, China)
X
1-9 36L9059 V66M X
1-9 36L9060 V66M China X
1-NS 02K2334 Screw for System Board X X
1-10 36L9070 AMD K6 2XT 333MHz 95FSB
(w/o heat sink and fan)
X
1-10 36L9122 AMD K6 2XT 350 MHz 100FSB
(w/o heatsink and fan)
X
1-10 36L9123 AMD K6 2XT 380 MHz 95FSB
(w/o heatsink and fan)
X
1-10 36L9124 AMD K6 2XT 400 MHz 100FSB
(w/o heatsink and fan)
X
1-10 36L9125 AMD K6 2XT 450 MHz 100FSB
(w/o heatsink and fan)
X
1-11 36L9148 Celeron 366 Mendocino X
1-11 36L9140 Celeron 400 Mendocino X
1-11 28L3842 Pentium II-350 W/ECC, 512K, 100 MHz X
1-11 20L2162 Pentium II-400 W/ECC, 512K, 100 MHz X
1-11 00K8476 Pentium II-450 W/ECC, 512K, 100 MHz X
1-11 36L9099 Pentium II-500 W/ECC, 512K, 100 MHz X
1-12 20L2187 2 Pin Power Connector, Fan Sink X
1-13 20L2163 Fan Sink 2 PIN(TDM) w/o t.d. Sunon X
1-14 20L2201 32MB module (PC-100) X X
1-14 20L2202 64MB module (PC-100) X X
Asm-
Index
FRU
Number
Description
Model
2158
Model
2163
To Next Page
