Installing the lower bezel
To install the lower bezel, complete the following steps:
1. Insert the two bottom tabs on the lower bezel into the corresponding holes in
the front of the chassis.
2. Rotate the top of the lower bezel up to the chassis; then, press the blue release
tab on the right side of the lower bezel and completely close the lower bezel
until it locks securely into place.
3. Lock the side cover.
4. Reconnect the external cables and power cords; then, turn on the attached
devices and turn on the server.
Chapter 4. Removing and replacing server components 55
