Installing a hot-swap power supply
This procedure applies only to server models that have hot-swap power supplies.
See “Installing a non-hot-swap power supply” on page 107 for information about the
installation of a non-hot-swap power supply.
To install a hot-swap power supply, complete the following steps:
1. Place the power supply into the bay guides.
Hot-swap power
supply
Release lever
2. Using the handle, push the power supply toward the front of the chassis until it
locks into place.
3. Connect one end of the power cord into the connector on the back of the power
supply and connect the other end of the power cord into a properly grounded
electrical outlet.
4. Make sure that both the ac and dc power LEDs on the rear of the power supply
are lit, indicating that the power supply is operating correctly.
74 System x3200 M2 Types 4367 and 4368: Problem Determination and Service Guide
