IBM 6550-23N - D Board Components

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by mark ¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque
¡ sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
6550-23N/23S/33N/63N/63S/73N
(a)
7-2
D105 8-719-970-83 DIODE HSS82
D106 8-719-970-83 DIODE HSS82
D111 8-719-062-51 DIODE 1PS226-115
D204 8-719-970-83 DIODE HSS82
D205 8-719-970-83 DIODE HSS82
D206 8-719-970-83 DIODE HSS82
D211 8-719-062-51 DIODE 1PS226-115
D304 8-719-970-83 DIODE HSS82
D305 8-719-970-83 DIODE HSS82
D306 8-719-970-83 DIODE HSS82
D311 8-719-062-51 DIODE 1PS226-115
<FERRITE BEAD>
FB001 1-412-911-11 FERRITE
FB002 1-412-911-11 FERRITE
FB004 1-412-911-11 FERRITE
FB005 1-412-911-11 FERRITE
FB006 1-412-911-11 FERRITE
FB009 1-412-911-11 FERRITE
FB010 1-412-911-11 FERRITE
FB011 1-412-911-11 FERRITE
FB012 1-412-911-11 FERRITE
FB014 1-412-911-11 FERRITE
FB015 1-412-911-11 FERRITE
FB016 1-412-911-11 FERRITE
FB017 1-412-911-11 FERRITE
FB018 1-412-911-11 FERRITE
FB019 1-412-911-11 FERRITE
FB102 1-216-295-91 SHORT 0
FB202 1-216-295-91 SHORT 0
FB302 1-216-295-91 SHORT 0
<FILTER>
FL002 1-412-911-11 FERRITE
<IC>
IC001 8-752-090-63 IC CXA2067S
IC002 8-759-593-11 IC LM2415
IC003 8-759-589-35 IC CXD9516P
IC004 8-749-016-27 IC H8D2957
IC005 8-759-100-96 IC uPC4558G2
IC006 8-759-269-07 IC SN74HCT02ANSR
<JACK>
J001 ¡ 1-451-499-11 SOCKET, PICTURE TUBE
<CHIP CONDUCTOR>
JR002 1-216-296-91 SHORT 0
JR005 1-216-296-91 SHORT 0
JR006 1-216-296-91 SHORT 0
JR007 1-216-296-91 SHORT 0
JR016 1-216-296-91 SHORT 0
JR017 1-216-296-91 SHORT 0
JR018 1-216-295-91 SHORT 0
JR019 1-216-296-91 SHORT 0
JR020 1-216-296-91 SHORT 0
JR021 1-216-296-91 SHORT 0
<COIL>
L002 1-410-682-31 INDUCTOR 470UH
L003 1-408-397-00 INDUCTOR 1UH
L005 1-412-529-11 INDUCTOR 22UH
L007 1-410-482-31 INDUCTOR 100UH
L009 1-216-295-91 SHORT 0
L010 1-412-911-11 FERRITE
L102 1-412-052-21 INDUCTOR CHIP 1UH
L103 1-414-137-31 INDUCTOR 0.22UH
L105 1-410-750-41 INDUCTOR 0.47UH
L203 1-414-137-31 INDUCTOR 0.22UH
L205 1-410-750-41 INDUCTOR 0.47UH
L303 1-414-137-31 INDUCTOR 0.22UH
L305 1-410-750-41 INDUCTOR 0.47UH
<TRANSISTOR>
Q001 8-729-046-80 TRANSISTOR 2SC4634LS-CB11
Q006 8-729-120-28 TRANSISTOR 2SC1623-L5L6
<RESISTOR>
R002 1-216-043-91 RES,CHIP 560 5% 1/10W
R003 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R004 1-216-055-00 RES,CHIP 1.8K 5% 1/10W
R005 1-216-121-91 RES,CHIP 1M 5% 1/10W
R006 1-216-025-91 RES,CHIP 100 5% 1/10W
R007 1-216-025-91 RES,CHIP 100 5% 1/10W
R009 1-216-073-00 RES,CHIP 10K 5% 1/10W
R011 1-216-073-00 RES,CHIP 10K 5% 1/10W
R012 1-216-073-00 RES,CHIP 10K 5% 1/10W
R013 1-216-025-91 RES,CHIP 100 5% 1/10W
R014 1-216-025-91 RES,CHIP 100 5% 1/10W
R017 1-216-025-91 RES,CHIP 100 5% 1/10W
R018 1-216-025-91 RES,CHIP 100 5% 1/10W
R020 1-216-025-91 RES,CHIP 100 5% 1/10W
R021 1-216-025-91 RES,CHIP 100 5% 1/10W
R022 1-216-033-00 RES,CHIP 220 5% 1/10W
R023 1-216-049-91 RES,CHIP 1K 5% 1/10W
R024 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R028 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R029 1-216-099-00 RES,CHIP 120K 5% 1/10W
R030 1-216-025-91 RES,CHIP 100 5% 1/10W
R031 1-216-049-91 RES,CHIP 1K 5% 1/10W
R035 1-216-295-91 SHORT 0
R041 1-216-025-91 RES,CHIP 100 5% 1/10W
R042 1-216-025-91 RES,CHIP 100 5% 1/10W
R045 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
