IBM 6550-23N - SECTION 7 ELECTRICAL PARTS LIST; A Board Components

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by mark ¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque
¡ sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
6550-23N/23S/33N/63N/63S/73N
NOTE:
The components identified by mark ¡
are critical for safety.
Replace only with part number specified.
When indicating parts by reference
number, please include the board name.
REF.NO. PART NO. DESCRIPTION REMARK
SECTION 7
ELECTRICAL PARTS LIST
REF.NO. PART NO. DESCRIPTION REMARK
Les composants identifiés par une
marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
The components identified by [ in this
manual have been carefully factory-
selected for each set in order to satisfy
regulations regarding X-ray radiation.
Should replacement be required, replace
only with the value originally used.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
(a)
RESISTORS
• All resistors are in ohms
• F : nonflammable
• Items marked " * " are not stocked since
they are seldom required for routine
service. Some delay should be
anticipated when ordering these items.
• CAPACITORS
MF : µF
• COILS
UH : µH
6550-23N/23S/33N/63N/63S/73N
7-1
* A-1294-732-A A BOARD, COMPLETE
***************************
4-382-854-11 SCREW (M3X10), P, SW (+) (IC002)
<CAPACITOR>
C001 1-162-318-11 CERAMIC 0.001MF 10% 500V
C002 1-106-220-00 MYLAR 0.1MF 10% 100V
C004 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C007 1-107-888-11 ELECT 47MF 20% 25V
C008 1-104-664-11 ELECT 47MF 20% 25V
C009 1-107-889-11 ELECT 220MF 20% 10V
C010 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C011 1-106-220-00 MYLAR 0.1MF 10% 100V
C012 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C014 1-107-932-11 ELECT 47MF 20% 100V
C015 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C016 1-128-528-11 ELECT 470MF 20% 16V
C017 1-104-664-11 ELECT 47MF 20% 25V
C018 1-107-961-91 ELECT 10MF 20% 250V
C022 1-104-664-11 ELECT 47MF 20% 25V
C027 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C028 1-104-664-11 ELECT 47MF 20% 25V
C029 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C032 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C033 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C035 1-162-134-11 CERAMIC 470PF 10% 2KV
C036 1-104-503-12 CERAMIC CHIP 0.1MF 10% 100V
C042 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C044 1-163-019-00 CERAMIC CHIP 0.0068MF 10% 50V
C046 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C047 1-107-888-11 ELECT 47MF 20% 25V
C049 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C050 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C053 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C054 1-137-528-11 FILM 0.1MF 10% 250V
C055 1-104-503-12 CERAMIC CHIP 0.1MF 10% 100V
C061 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C090 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C092 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C102 1-137-528-11 FILM 0.1MF 10% 250V
C104 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C105 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C106 1-137-528-11 FILM 0.1MF 10% 250V
C112 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C130 1-216-295-91 SHORT 0
C151 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C202 1-137-528-11 FILM 0.1MF 10% 250V
C204 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C205 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C206 1-137-528-11 FILM 0.1MF 10% 250V
C212 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C230 1-216-295-91 SHORT 0
C251 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C302 1-137-528-11 FILM 0.1MF 10% 250V
C304 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C305 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C306 1-137-528-11 FILM 0.1MF 10% 250V
C312 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C330 1-216-295-91 SHORT 0
C351 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
<CONNECTOR>
CN301 1-506-108-41 PIN, CONNECTOR (TERMINAL PIN)
CN303 1-695-915-11 TAB (CONTACT)
CN304 1-695-915-11 TAB (CONTACT)
CN305*1-564-512-11 PLUG, CONNECTOR 9P
CN306*1-564-509-11 PLUG, CONNECTOR 6P
CN309*1-564-511-11 PLUG, CONNECTOR 8P
CN310*1-564-507-11 PLUG, CONNECTOR 4P
CN311*1-564-508-11 PLUG, CONNECTOR 5P
CN313*1-564-512-11 PLUG, CONNECTOR 9P
<DIODE>
D001 8-719-970-02 DIODE 1SR139-400T31
D002 8-719-911-19 DIODE 1SS119-25
D003 8-719-911-19 DIODE 1SS119-25
D004 8-719-911-19 DIODE 1SS119-25
D005 8-719-911-19 DIODE 1SS119-25
D007 8-719-109-89 ZENER DIODE RD5.6ESB2
D008 8-719-109-89 ZENER DIODE RD5.6ESB2
D014 8-719-911-19 DIODE 1SS119-25
D015 8-719-911-19 DIODE 1SS119-25
D104 8-719-970-83 DIODE HSS82
