Modem
Data/fax modem software
program invokes but cannot
receive/send data/fax
See “Factory-Installed Modem Card” on page 52.
Fax/voice modem software
program invokes but has no
sound output. (Data files are
received normally; voice from
modem cannot be produced,
but system sound feature
works normally.)
Ensure that the modem voice-in cable from modem
adapter card to system board CN13(for 2158) or
CN8(for 2163/2164) is connected properly. See
“Machine Type 2158 System Board Jumpers and
Connectors” on page 131 and “Machine Type 2163
and 2164 System Board Jumpers and Connectors”
on page 135.
“Factory-Installed Modem Card” on page 52.
Modem ring cannot wake up
system from suspend mode.
Ensure the “Modem Wake-Up on Ring” in BIOS
Setup is set to [Enabled]. See “Power Management
Mode” on page 17.
If PCI modem card is used, reinsert the modem card
to PCI slot firmly or replace modem card.
If ISA modem card is used, ensure the modem ring-
in cable from the modem card to system board
CN8(for 2158) or CN13(for 2163/2164) is connected
properly. See “Machine Type 2158 System Board
Jumpers and Connectors” on page 131 and
“Machine Type 2163 and 2164 System Board
Jumpers and Connectors” on page 135.
In Win 98 ensure that telephone application is
configured correctly for your modem and set to
receive messages and/or fax.
Video and Monitor
Video memory test failed.
Video adapter failed.
Remove all non factory-installed cards.
Load default settings (if screen is readable).
System board
Table 2-3 Error Symptoms List
(Continued)
NOTE:
To diagnose a problem, first find the error symptom in the left column. If directed
to a check procedure, replace the FRU indicated in the check procedure. If no
check procedure is indicated, the first Action/FRU listed in right column is the
most likely cause.
Error Symptoms Action/FRU
To Next Page
