IBM BladeCenter HS22 Product Guide

IBM BladeCenter HS22 12
I/O expansion options
The HS22 server offers the following PCI Express 2.0 slots, neither of which is hot-swap.
CIOv expansion slot

CFFh expansion slot

The CIOv I/O expansion connector provides I/O connections through the midplane of the chassis to
modules located in bays 3 and 4 of a supported BladeCenter chassis. It is a PCIe 2.0 x8 slot.
The CFFh I/O expansion connector provides I/O connections to high-speed switch modules that are
located in bays 7, 8, 9, and 10 of a BladeCenter H or BladeCenter HT chassis, or to switch bay 2 in a
BladeCenter S chassis. The CFFh slot is a PCIe x16 slot.
The HS22 optionally supports the IBM BladeCenter PCIe Gen 2 Expansion Blade. The expansion blade
provides the capability to attach selected PCI Express cards to the HS22. This capability is ideal for many
applications that require special telecommunications network interfaces or hardware acceleration using a
PCI Express card.
The expansion blade provides one full height and full length PCI Express slot and one full height and half
length PCI Express slot with a maximum power usage of 75 watts for each slot. It integrates PCI Express
card support capability into the BladeCenter architecture. Up to four expansion blades can be attached to
an HS22. Each expansion blade occupies a bay in the BladeCenter chassis.
The server also supports IBM BladeCenter PCI Express I/O Expansion Unit (PCI Express Gen 1). A
maximum of one unit can be attached to a single blade.
Table 10. Expansion blades
Part
number
Feature
code
Description Maximum
supported
46M6730 9295 IBM BladeCenter PCI Express Gen 2 Expansion Blade 4
68Y7484 A247 IBM BladeCenter PCI Express Gen 2 Expansion Blade II 4
43W4391 4339 IBM BladeCenter PCI Express I/O Expansion Unit 1
46M6771 A25F IBM BladeCenter GPU Expansion Blade with NVIDIA Tesla M2075 3
46M6772 A10R IBM BladeCenter GPU Expansion Blade with NVIDIA Tesla M2070Q 3
46M6740 5090 IBM BladeCenter GPU Expansion Blade with NVIDIA Tesla M2070 (CTO
Only)
3
68Y7478 A245 IBM BladeCenter GPU Expansion Blade II with NVIDIA Tesla M2075 3
68Y7479 A246 IBM BladeCenter GPU Expansion Blade II with NVIDIA Tesla M2070Q 3
For more information, see the following IBM Redbooks Product Guide publications:
IBM BladeCenter PCI Express Gen 2 Expansion Blade and PCI Express Gen 2 Expansion Blade II at:

http://www.redbooks.ibm.com/abstracts/tips0783.html?Open
IBM BladeCenter GPU Expansion Blade and GPU Expansion Blade II at:

http://www.redbooks.ibm.com/abstracts/tips0798.html?Open

IBM BladeCenter HS22 Specifications

General

Tcase	76.2 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBZ8
Processor cache	12 MB
Processor cores	6
Processor model	E5649
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	12
Processor codename	Westmere EP
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	1333 MHz
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	19
Maximum number of SMP processors	2
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066/1333
Memory channels supported by processor	Triple
Memory bandwidth supported by processor (max)	32 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	0 GB
Maximum storage capacity	1 TB
Number of HDDs installed	0
Internal memory	12 GB
Memory clock speed	- MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	3 x 4 GB
Graphics card	G200eV
Graphics card memory type	GDDR2
Networking features	Gigabit Ethernet
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible operating systems	Microsoft Windows RedHat, SUSE, VMware Oracle Solaris
Chassis type	Rack (1U)
Processor ARK ID	52581
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	446 mm
Width	245 mm
Height	29 mm
Weight	5400 g
