IBM BladeCenter HS22 Product Guide

IBM BladeCenter HS22 5
Chassis support
The HS22 is supported in the various BladeCenter chassis as listed in the following table.
Table 4. Chassis support
Description BC-E
(8677)
BC-T BC-S
(8886)
BC-H
(8852)
BC-HT AC
(8750)
BC-HT DC
(8740)
HS22 with 130W processors No No Some
limits*
Some
limits*
Some
limits*
Some limits*
HS22 with up to 95W processors Some
limits*
No Full Full Full Full
* See Table 5 for details
The number of HS22 servers supported in each chassis depends on the thermal design power of the
processors used in the servers, as shown in Table 5. The table uses the following conventions:
A green cell means the chassis can be filled with HS22 blade servers up to the maximum number of

blade bays in the chassis (for example, 14 blades in the BladeCenter H).
A yellow cell means that the maximum number of HS22 blades that the chassis can hold is fewer than

the total available blade bays (for example, 12 in a BladeCenter H). Other bays in the chassis may or
may not be occupied by servers other than HS22 and HS22V depending on the combination and
some bays must remain empty. Consult the BladeCenter Interoperability Guide for specifics:
http://ibm.com/support/entry/portal/docdisplay?lndocid=MIGR-5073016
Note: The HS22 is not supported in the BladeCenter E with power supplies smaller than 2000 W.
Table 5. Chassis support (detailed)
Maximum number of HS22 servers supported in each chassis
BC-E with AMM
(8677) (14 bays)
BC-H (models other than 4Tx)
(14 bays)
BC-H
(-4Tx)
(14 bays)
2900W supplies 2980W supplies** 2980W
CPU
TDP*
2000 W
power
supplie
s
2320 W
power
supplie
s
BC-S
(8886)
(6
bays)
Standard
blowers
Enhanced
blowers†
Standard
blowers
Enhanced
blowers†
Enhanced
blowers†
BC-HT
AC
(8750)
(12
bays)
BC-HT
DC
(8740)
(12 bays)
130W None‡ None‡ 5 None‡ 12 None‡ 14 14 10 10
95W 6 14 6 14 14 14 14 14 12 12
80W 12 14 6 14 14 14 14 14 12 12
60W 13 14 6 14 14 14 14 14 12 12
40W 14 14 6 14 14 14 14 14 12 12
* Thermal Design Power
** IBM BladeCenter H 2980W AC Power Modules, 68Y6601 (standard in 4Tx, optional with all other BC-H chassis
models)
† IBM BladeCenter H Enhanced Cooling Modules, 68Y6650 (standard in 4Tx, optional with all other BC-H chassis
models)
‡ Not supported

IBM BladeCenter HS22 Specifications

General

Tcase	76.2 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBZ8
Processor cache	12 MB
Processor cores	6
Processor model	E5649
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	12
Processor codename	Westmere EP
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	1333 MHz
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	19
Maximum number of SMP processors	2
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066/1333
Memory channels supported by processor	Triple
Memory bandwidth supported by processor (max)	32 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	0 GB
Maximum storage capacity	1 TB
Number of HDDs installed	0
Internal memory	12 GB
Memory clock speed	- MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	3 x 4 GB
Graphics card	G200eV
Graphics card memory type	GDDR2
Networking features	Gigabit Ethernet
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible operating systems	Microsoft Windows RedHat, SUSE, VMware Oracle Solaris
Chassis type	Rack (1U)
Processor ARK ID	52581
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	446 mm
Width	245 mm
Height	29 mm
Weight	5400 g
