IBM BladeCenter HS22 Product Guide

IBM BladeCenter HS22 3
Standard specifications
The following table lists the standard specifications.
Table 1. Standard specifications
Components Specification
Form factor Single-wide (30 mm)
Processor model Intel Xeon 5600 series processors, up to 3.6 GHz
Intel Xeon 5500 series processors, up to 2.80 GHz
Number of
processors
1 standard / 2 maximum
L3 cache Up to 12 MB L3 cache
Chipset Intel 5520 chipset
Memory DIMM
sockets
12x DDR-3 VLP DIMM slots
Maximum
memory
Models with Intel Xeon 5600 series processors: 192 GB using 16GB DIMMs
Models with Intel Xeon 5500 series processors: 96 GB using 8GB DIMMs
Expansion slots One CIOv slot: 2 ports
One CFFh slot: 4 ports
Disk controller LSI Logic 1064E SAS 3 Gbps controller, supports RAID-0 & RAID-1
Optional ServeRAID MR10ie with battery-backed write cache for internal and external disk
drives
Disk bays
(total/hot-swap)
Two hot-swap 2.5-inch SFF bays supporting SAS HDDs or solid-state drives
Maximum
internal storage
Up to 2 TB total internal storage (using 1TB NL SAS or NL SATA drives)
Network
interface
2x 1Gb Ethernet using a Broadcom BCM5709S onboard NIC; supports TOE, failover and load
balancing, Wake on LAN, PXE boot
Some models also include a 2-port 10Gb controller installed in the CFFh slot (Emulex 10 GbE
Virtual Fabric Adapter Advanced II or QLogic 2-port 10 Gb Converged Network Adapter,
depending on the model)
Hot-swap
components
Internal storage bays
Systems
management
Unified Extensible Firmware Interface (UEFI), IBM Integrated Management Module (IMM),
Predictive Failure Analysis, optional embedded hypervisor for virtualization, IBM Systems
Director Active Energy Manager, light path diagnostics, IBM Systems Director and IBM
ServerGuide
Video Matrox G200eV video core with 16 MB of video memory
Security Trusted Platform Module (TPM), Power-on password, administrator password, unattended
boot, selectable boot, unattended start mode
Operating
systems
supported
Microsoft Windows, Red Hat Enterprise Linux, SUSE Linux Enterprise, VMware, Oracle Solaris
Limited warranty Three-year customer replaceable unit and on-site and off-site limited warranty

IBM BladeCenter HS22 Specifications

General

Tcase	76.2 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBZ8
Processor cache	12 MB
Processor cores	6
Processor model	E5649
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	12
Processor codename	Westmere EP
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	1333 MHz
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	19
Maximum number of SMP processors	2
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066/1333
Memory channels supported by processor	Triple
Memory bandwidth supported by processor (max)	32 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	0 GB
Maximum storage capacity	1 TB
Number of HDDs installed	0
Internal memory	12 GB
Memory clock speed	- MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	3 x 4 GB
Graphics card	G200eV
Graphics card memory type	GDDR2
Networking features	Gigabit Ethernet
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible operating systems	Microsoft Windows RedHat, SUSE, VMware Oracle Solaris
Chassis type	Rack (1U)
Processor ARK ID	52581
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	446 mm
Width	245 mm
Height	29 mm
Weight	5400 g
