IBM BladeCenter HS22 Product Guide

IBM BladeCenter HS22 6
Processor options
The HS22 supports the processor options listed in the following table. The server supports one or two
processors. The table also shows which server models have each processor standard. If no
corresponding where used model for a particular processor is listed, then this processor is available only
through Configure to Order (CTO).
Table 6. Processor options (Part 1)
Part
number
Intel Xeon processor description Models
where used
Intel Xeon 5600 Series Processors: 4-core
81Y9323 Xeon E5603 4C 1.60GHz 4MB 1066MHz 80w A5x
81Y9324 Xeon E5606 4C 2.13GHz 8MB 1066MHz 80w -
81Y9325 Xeon E5607 4C 2.26GHz 8MB 1066MHz 80w A7x
59Y5705 Xeon E5620 4C 2.40GHz 12MB 1066MHz 80w G2x
59Y5707 Xeon E5630 4C 2.53GHz 12MB 1066MHz 80w -
59Y5708 Xeon E5640 4C 2.66GHz 12MB 1066MHz 80w G4x, GCx
49Y5184 Xeon L5609 4C 1.86GHz 12MB 1066MHz 40w -
59Y5704 Xeon L5630 4C 2.13GHz 12MB 1066MHz 40w -
81Y9326 Xeon X5647 4C 2.93GHz 12MB 1066MHz 130w B5x
59Y5712 Xeon X5667 4C 3.06GHz 12MB 1333MHz 95w H5x
81Y9328 Xeon X5672 4C 3.20GHz 12MB 1333MHz 95w C5x
59Y5714 Xeon X5677 4C 3.46GHz 12MB 1333MHz 130w F3x
81Y9330 Xeon X5687 4C 3.60GHz 12MB 1333MHz 130w C7x
Intel Xeon 5600 Series Processors: 6-core
68Y8125 Xeon E5645 6C 2.40GHz 12MB 1333MHz 80w 91x, 92x
81Y9327 Xeon E5649 6C 2.53GHz 12MB 1333MHz 80w B6x, D4x
68Y8124 Xeon L5638 6C 2.0GHz 12MB 1333MHz 60w -
59Y5706 Xeon L5640 6C 2.26GHz 12M 1333MHz 60w N2x
59Y5709 Xeon X5650 6C 2.66GHz 12M 1333MHz 95w H2x, HAx
59Y5710 Xeon X5660 6C 2.80GHz 12MB 1333MHz 95w -
59Y5711 Xeon X5670 6C 2.93GHz 12MB 1333MHz 95w H4x
81Y9329 Xeon X5675 6C 3.06GHz 12MB 1333MHz 95w C6x
59Y5713 Xeon X5680 6C 3.33GHz 12MB 1333MHz 130w F2x
81Y9331 Xeon X5690 6C 3.46GHz 12MB 1333MHz 130w C8x

IBM BladeCenter HS22 Specifications

General

Tcase	76.2 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBZ8
Processor cache	12 MB
Processor cores	6
Processor model	E5649
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	12
Processor codename	Westmere EP
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	1333 MHz
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	19
Maximum number of SMP processors	2
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066/1333
Memory channels supported by processor	Triple
Memory bandwidth supported by processor (max)	32 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	0 GB
Maximum storage capacity	1 TB
Number of HDDs installed	0
Internal memory	12 GB
Memory clock speed	- MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	3 x 4 GB
Graphics card	G200eV
Graphics card memory type	GDDR2
Networking features	Gigabit Ethernet
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible operating systems	Microsoft Windows RedHat, SUSE, VMware Oracle Solaris
Chassis type	Rack (1U)
Processor ARK ID	52581
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	446 mm
Width	245 mm
Height	29 mm
Weight	5400 g
