IBM BladeCenter HS22 Product Guide

IBM BladeCenter HS22 13
Network adapters
The HS22 offers two integrated Gigabit Ethernet ports, based on the Broadcom BCM5709S controller.
Failover, adapter fault tolerance

PXE 2.0 Boot Agent

Wake on LAN

Load balancing or teaming

The following table lists additional supported network adapters.
Table 11. Network adapters
Part
number
Feature
code
Description Slots
supported
10 Gb
Ethernet
46M6164 0098 Broadcom 10Gb Gen2 4-port Ethernet Exp Cd (CFFh) CFFh
81Y3133 A1QR Broadcom 2-port 10Gb Virtual Fabric Adapter for IBM BladeCenter CFFh
81Y1650 5437 Brocade 2 port 10GbE Converged Network Adapter for IBM BladeCenter CFFh
00Y3264 A3NW Emulex 10GbE Virtual Fabric Adapter Advanced II - IBM BladeCenter CFFh
90Y3566 A1XH Emulex 10GbE Virtual Fabric Adapter Advanced II - IBM BladeCenter CFFh
49Y4265 2436 Emulex 10GbE Virtual Fabric Advanced Upgrade for IBM BladeCenter (license)
00Y3266 A3NV Emulex 10GbE Virtual Fabric Adapter II - IBM BladeCenter CFFh
90Y3550 A1XG Emulex 10GbE Virtual Fabric Adapter II - IBM BladeCenter CFFh
42C1810 3593 Intel 10Gb 2-port Ethernet Expansion Card (CFFh) for IBM BladeCenter CFFh
90Y3570 A1NW Mellanox 2-port 10Gb Enet Expansion Card (CFFh) - IBM BladeCenter CFFh
00Y3280 A3JB QLogic 2-port 10Gb CNA (CFFh) for IBM BladeCenter CFFh
42C1830 3592 QLogic 2-pt 10Gb Converged Network Adapter(CFFh) CFFh
00Y3270 A3JC QLogic Enet and 8Gb FC Exp Card (CFFh) for IBM BladeCenter CFFh
44X1940 5485 QLogic Eth and 8Gb Fibre Channel Exp Card (CFFh) CFFh
1 Gb Ethernet
44W4479 5476 2/4 Port Ethernet Expansion Card (CFFh) for IBM BladeCenter CFFh
44W4475 5477 Ethernet Expansion Card (CIOv) for IBM BladeCenter CIOv
InfiniBand
46M6001 0056 2-port 40Gb Infiniband Expansion Card (CFFh) for IBM BladeCenter CFFh
43W4423 2991 4X InfiniBand DDR Expansion Card (CFFh) for IBM BladeCenter CFFh
43W4420 2993 Voltaire 4X InfiniBand DDR Expansion Card (CFFh) CFFh
For more information, see the list of IBM Redbooks Product Guides in the Ethernet adapters category:
http://www.redbooks.ibm.com/portals/BladeCenter?Open&page=pg&cat=ethadapters

IBM BladeCenter HS22 Specifications

General

Tcase	76.2 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBZ8
Processor cache	12 MB
Processor cores	6
Processor model	E5649
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	12
Processor codename	Westmere EP
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	1333 MHz
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	19
Maximum number of SMP processors	2
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066/1333
Memory channels supported by processor	Triple
Memory bandwidth supported by processor (max)	32 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	0 GB
Maximum storage capacity	1 TB
Number of HDDs installed	0
Internal memory	12 GB
Memory clock speed	- MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	3 x 4 GB
Graphics card	G200eV
Graphics card memory type	GDDR2
Networking features	Gigabit Ethernet
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible operating systems	Microsoft Windows RedHat, SUSE, VMware Oracle Solaris
Chassis type	Rack (1U)
Processor ARK ID	52581
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	446 mm
Width	245 mm
Height	29 mm
Weight	5400 g
