IBM BladeCenter HS22 Product Guide

IBM BladeCenter HS22 20
Note: If the ServeRAID MR10ie is installed, the battery is installed in DIMM slot 7. Therefore DIMM slot 7
cannot be used for memory. This will limit the total amount of memory that will be able to be installed.
The ServeRAID MR10ie Controller has the following specifications:
Two SAS ports routed internally to the chassis I/O bays 3 and 4

Supports RAID levels 0, 1, 5, 6, 10, 50, and 60

Provides 256 MB of ECC DDR-2 battery-backed cache

3 Gbps throughput per port

PCI Express 1.0 x4 host interface

Based on the LSI 1078 controller

Supports up to 26 disk drives.

Support for on-board and external disk drives

Supports connectivity to the EXP3000 storage expansion enclosures

The following table lists the drives supported by EXP3000 external expansion enclosure.
Table 19. Hard drive options for external expansion enclosures
Part
number
Description Maximum quantity supported per
enclosure
EXP3000 Hot-Swap SATA 3.5" Hard Drives
49Y1940 IBM 2 TB 7200 Dual Port SATA 3.5'' HS HDD 12
EXP3000 Hot-Swap SAS 3.5" Hard Drives
44W2234 IBM 300 GB 15K 6 Gbps SAS 3.5" Hot-Swap HDD 12
44W2239 IBM 450 GB 15K 6 Gbps SAS 3.5" Hot-Swap HDD 12
44W2244 IBM 600 GB 15K 6 Gbps SAS 3.5" Hot-Swap HDD 12
The following table lists the drives supported by EXP2512 external expansion enclosures.
Table 20. Drive options for the EXP2512 external expansion enclosures
Part number Description Maximum quantity supported
per one enclosure
NL SAS 3.5-inch HDDs
49Y1903 1TB 7,200 rpm 6Gb SAS NL 3.5" HDD 12
49Y1902 2TB 7,200 rpm 6Gb SAS NL 3.5" HDD 12
90Y8720 3TB 7,200 rpm 6Gb SAS NL 3.5" HDD 12
SAS 3.5-inch HDDs
49Y1899 300GB 15,000 rpm 6Gb SAS 3.5" HDD 12
49Y1900 450GB 15,000 rpm 6Gb SAS 3.5" HDD 12
49Y1901 600GB 15,000 rpm 6Gb SAS 3.5" HDD 12

IBM BladeCenter HS22 Specifications

General

Tcase	76.2 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBZ8
Processor cache	12 MB
Processor cores	6
Processor model	E5649
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	12
Processor codename	Westmere EP
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	1333 MHz
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	19
Maximum number of SMP processors	2
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066/1333
Memory channels supported by processor	Triple
Memory bandwidth supported by processor (max)	32 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	0 GB
Maximum storage capacity	1 TB
Number of HDDs installed	0
Internal memory	12 GB
Memory clock speed	- MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	3 x 4 GB
Graphics card	G200eV
Graphics card memory type	GDDR2
Networking features	Gigabit Ethernet
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible operating systems	Microsoft Windows RedHat, SUSE, VMware Oracle Solaris
Chassis type	Rack (1U)
Processor ARK ID	52581
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	446 mm
Width	245 mm
Height	29 mm
Weight	5400 g
