IBM BladeCenter HS22 Product Guide

IBM BladeCenter HS22 9
Table 8. Memory options for servers with Xeon 5600 series processors
Part
number
Feature
code
Description Models
where
used
Standard DIMMs (1.5 V)
49Y1427 8928 1GB (1x 1GB, 1Rx8, 1.5V) PC3-10600 CL9 ECC DDR3 1333 -
49Y1428 8929 2GB (1x 2GB, 2Rx8, 1.5V) PC3-10600 CL9 ECC DDR3 1333 F2x, F3x, G2x,
G4x, GCx, H2x,
H4x, H5x, HAx,
N2x
49Y1429 8930 2GB (1x 2GB, 1Rx4, 1.5V) PC3-10600 CL9 ECC DDR3 1333 -
44T1594 A0YV 2GB (1x 2GB, 1Rx8, 1.5V) PC3-10600 CL9 ECC DDR3 1333 -
49Y1430 8931 4GB (1x 4GB, 2Rx4, 1.5V) PC3-10600 CL9 ECC DDR3 1333 -
49Y1431 8932 8GB (1x 8GB, 2Rx4, 1.5V) PC3-10600 CL9 ECC DDR3 1333 -
Low Power DIMMs (1.35 V)
46C0560 A0WX 2GB (1x 2GB, 1Rx8, 1.35V) PC3L-10600 CL9 ECC DDR3 1333 -
46C0563 A0WY 4GB (1x 4GB, 1Rx4, 1.35V) PC3L-10600 CL9 ECC DDR3 1333 A5x, A7x, B5x,
B6x, C5x, C6x,
C7x, C8x
46C0564 A0WZ 4GB (1x 4GB, 2Rx8, 1.35V) PC3L-10600 CL9 ECC DDR3 1333 -
46C0568 8644 8GB (1x 8GB, 2Rx4, 1.35V) PC3-10600 CL9 ECC DDR3 1333 -
46C0599 2422 16GB (1x16 GB, 2Rx4, 1.35V) PC3L-10600 CL9 ECC DDR3 1333 -
Note that although the maximum speed at which the memory channel runs on the HS22 is 1333 MHz, this
depends on a combination of three items:
Processor memory speed: The processor has a maximum memory speed of 1333, 1066, or 800 MHz

depending on the processor model. Only the X (Advanced) range of Xeon 5500 and 5600 series
processors supports a maximum memory channel speed of 1333 MHz. See the processor options
(Table 5) for the maximum memory speed.
Memory DIMM: Most but not all DIMMs listed in the previous tables support running at 1333 MHz.

Some only run at 1066 MHz. This is noted in the description of the DIMM.
Number of DIMMs installed: The HS22 implements memory so that 2 DIMMs are on each of the three

memory channels of the processor. if only 1 DIMM is installed to each channel (that is, 3 DIMMs per
processor) then the DIMMs can operate at the lower of the DIMM rated speed and processor memory
channel rated speed, up to 1333 MHz. However at 2 DIMMs per channel (6 DIMMs per processor),
memory can only operate at 1333 MHz if Xeon 5600 X (Advanced) range of processors (models
X56nn) are installed. All other processors (all 5500, L56nn, and E56nn) cannot drive the memory
channel at 1333 MHz if there are 2 DIMMs per channel.
In summary, to ensure DIMMs operate at 1333 MHz, select a Xeon X56nn processor and use DIMMs that
are rated at 1333 MHz. All DIMMs in the proceeding table support running at 2 DIMMs per channel at
1333 MHz.

IBM BladeCenter HS22 Specifications

General

Tcase	76.2 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBZ8
Processor cache	12 MB
Processor cores	6
Processor model	E5649
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	12
Processor codename	Westmere EP
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	1333 MHz
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	19
Maximum number of SMP processors	2
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066/1333
Memory channels supported by processor	Triple
Memory bandwidth supported by processor (max)	32 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	0 GB
Maximum storage capacity	1 TB
Number of HDDs installed	0
Internal memory	12 GB
Memory clock speed	- MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	3 x 4 GB
Graphics card	G200eV
Graphics card memory type	GDDR2
Networking features	Gigabit Ethernet
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible operating systems	Microsoft Windows RedHat, SUSE, VMware Oracle Solaris
Chassis type	Rack (1U)
Processor ARK ID	52581
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	446 mm
Width	245 mm
Height	29 mm
Weight	5400 g
