IBM Elastic Storage System 3000 User Manual

Chapter 3. Part Listings
View a complete list of CRU and FRU information.
In addition to a detailed list of CRU and FRU information along with their part numbers, you can also view
the part numbers for FRU - Cables in a separate list.
CRU part number list
The CRU part numbers are listed in the table.
CRU Part Numbers List
Table 9. CRU Part Numbers
Description Part Number
SFF Enclosure bezel, right 00Y2512
2000 W AC PSU 01YM310
Power Interposer 01YM314
Rail kit 01YM317
1.92 TB 2.5" NVMe Flash drive 01LL512
3.84 TB 2.5" NVMe Flash drive 01LL513
7.68 TB 2.5" NVMe Flash drive 01LL514
15.36 TB 2.5" NVMe Flash drive 01LL515
Left Brand Bezel 01LL519
FRU part number list
The FRU part numbers are listed in the table.
FRU Part Number
Table 10. FRU Part Numbers
Description Part Number
PCIe4 LP 2-port 100 Gb EDR IB CAPI adapter 0000000WT176
100 GbE Optical Transceiver QSFP28 0000001FT706
PCIe4 LP 2-port 100 Gb ROCE EN LP adapter 0000001FT742
Altsrc 2P100HP (*Arab Nation orders, China
Source)
0000001FT769
2-Port 100G LP (*Arab Nation orders, China
Source)
0000001FT812
Node canister: ESS 3000 (5141-AF8) 0000001LL518
END7 Power Cable - Drawer to IBM PDU - C13/C20
(250V/10A) for India
0000001PP687
©
Copyright IBM Corp. 2019, 2020 47
