Table 1. Tasks to install the deskside server (continued)
Task Where to find associated information
Remove the shipping bracket on the back left of the
system that protects the power supplies. This shipping
bracket is not needed for system installation. Ensure you
have re-seated the power supplies.
To remove the shipping bracket, do the following:
1. Remove the screws.
2. Pull the power supplies out slightly so that you can
remove the shipping bracket.
3. Re-seat the power supplies.
Connect your expansion unit, disk drives, and PCI
adapters, if applicable.
Note: Do not power on your system until you return to
this guide.
For more information, see Enclosures and expansion
units (http://publib.boulder.ibm.com/infocenter/
systems/scope/hw/topic/p7ham/expansionunit.htm),
Disk drives (http://publib.boulder.ibm.com/infocenter/
systems/scope/hw/topic/p7hal/p7halkickoff.htm), and
Model 8202-E4B or 8205-E6B PCI adapters
(http://publib.boulder.ibm.com/infocenter/systems/
scope/hw/topic/p7hak/p8202pcianddiv.htm). When you
are finished, continue with the next task.
Cable the system and set up a console, interface, or
terminal.
To cable the system, see Cable the system and set up a
console, interface, or terminal.
Connect power cables and apply power. For more information, see Completing server setup if
you have an HMC, or Completing server setup if you do
not have an HMC
Installing the IBM Power 720 Express (8202-E4B) and the IBM Power 740 Express (8205-E6B) 3
