CAUTION:
The stabilizer must be firmly attached to the bottom front of the rack to prevent
the rack from turning over when the drawers are pulled out of the rack. Do not
pull out or install any drawer or feature if the stabilizer is not attached to the
rack.
CAUTION:
The stabilizer must be firmly attached to the bottom rear of the rack to prevent
the rack from turning over when the drawers are pulled out of the rack. Do not
pull out or install any drawer or feature if the stabilizer is not attached to the
rack.
R
R
R
CEC Drawer
(8 EIA Units)
CEC Drawer
(8 EIA Units)
Primary
I/O Drawer
(5 EIA Units)
Primary
I/O Drawer
(5 EIA Units)
Secondary
I/O Drawer
(Optional)
(5 EIA Units)
System unit with
Two I/O Drawers
System unit with
One I/O Drawer
