IBM Storwize V5030 Quick Installation Guide

management arms also support the SAS cables.
Important: Always secure each power cable with a cable retainer and ensure
that the cable is installed along one of the cable management arms. When
secured, the power and SAS cables stay connected when you slide the
expansion enclosure out of the rack to perform service tasks.
1
2
svc01083
Figure 116. Secure power cables
Chapter 2. Installing the system hardware 133

IBM Storwize V5030 Specifications

General

Model	IBM Storwize V5030
Category	Storage
Controller Enclosures	1 or 2
Maximum Drives	240
RAID Levels	0, 1, 5, 6, 10
Virtualization	Yes
Data Compression	Yes
Maximum Hosts	512
Form Factor	2U
Drive Types	SAS, NL-SAS, SSD
Host Interface	8 Gb FC, 16 Gb FC, 10 Gb iSCSI, 12 Gb SAS
Processor Cores	8 per controller
