IBM System p Series

Back view of a model 9110-510 server
View the ports and connections on the model 9110-510 server.
Use the following diagram to help you cable a model 9110-510 server. Connections and ports are labeled
to facilitate the setup process.
Figure 17. Back views of a model 9111-285 workstation
Cabling your server 173
