5. To ship the server, repackage it in the original undamaged packing material and
observe IBM procedures for shipping.
Support information for IBM Business Partners is available at http://www.ibm.com/
partnerworld/.
Server components
The following illustration shows the major components in the server (depending on
the server model). The illustrations in this document might differ slightly from your
hardware.
See the PDSG on the System x Documentation CD for additional information about
the server.
Chassis
assembly
Side cover
System board
Bezel
Microprocessor
Heat sink
Power supply
Memory
Hard disk
drive
System fan
DVD drive
Filler
18 System x3100 M4 Type 2582: Installation and User's Guide
