IBM System x3550 M3 12

The server supports the processor options listed in the following table. The server supports up to two

processors. The table shows which server models have each processor standard. If there is no

corresponding

where-used

model for a particular processor, then this model is only available through

CTO.

Table 4. Processor options (part 1)

Part

number

Feature

code

Description Models

where used

Intel Xeon 5600 series processors

81Y6548 A0ZN Intel Xeon E5603 4C 1.60 GHz 4 MB Cache 1066 MHz 80w (with fan) 12x

81Y6549 A0ZP Intel Xeon E5606 4C 2.13 GHz 8 MB Cache 1066 MHz 80w (with fan) 22x

81Y6550 A0ZQ Intel Xeon E5607 4C 2.26 GHz 8 MB Cache 1066 MHz 80 w (with fan) 32x, E4x

59Y4006 4600 Intel Xeon E5620 4C 2.40 GHz 12 MB Cache 1066 MHz 80 w (with fan) D2x, D4x

59Y4007 4601 Intel Xeon E5630 4C 2.53 GHz 12 MB Cache 1066 MHz 80 w (with fan) -

59Y4008 4602 Intel Xeon E5640 4C 2.66 GHz 12 MB Cache 1066 MHz 80 w (with fan) -

81Y6547 A0ZM Intel Xeon E5645 6C 2.40 GHz 12 MB Cache 1333 MHz 80w (with fan) 52x, 54x

81Y6552 A0ZS Intel Xeon E5649 6C 2.53 GHz 12 MB Cache 1333 MHz 80w (with fan) 62x, E5x

59Y4003 4597 Intel Xeon L5609 4C 1.86 GHz 12 MB Cache 1066 MHz 40 w (with fan) -

59Y4004 4598 Intel Xeon L5630 4C 2.13 GHz 12 MB Cache 1066 MHz 40 w (with fan) -

59Y4005 4599 Intel Xeon L5640 6C 2.26 GHz 12 MB Cache 1333 MHz 60 w (with fan) -

81Y6551 A0ZR Intel Xeon X5647 4C 2.93 GHz 12 MB Cache 1333 MHz 130w (with fan) -

59Y4009 4603 Intel Xeon X5650 6C 2.66 GHz 12 MB Cache 1333 MHz 95 w (with fan) J4x, E6x

59Y4010 4604 Intel Xeon X5660 6C 2.80 GHz 12 MB Cache 1333 MHz 95 w (with fan) -

59Y4012 4606 Intel Xeon X5667 4C 3.06 GHz 12 MB Cache 1333 MHz 95 w (with fan) -

59Y4011 4605 Intel Xeon X5670 6C 2.93 GHz 12 MB Cache 1333 MHz 95 w (with fan) -

81Y6553 A0ZT Intel Xeon X5672 4C 3.20 GHz 12 MB Cache 1333 MHz 95w (with fan) -

81Y6554 A0ZU Intel Xeon X5675 6C 3.06 GHz 12 MB Cache 1333 MHz 95w (with fan) 72x

59Y4013 4607 Intel Xeon X5677 4C 3.46 GHz 12 MB Cache 1333 MHz 130 w (with fan) -

59Y4014 4608 Intel Xeon X5680 6C 3.33 GHz 12 MB Cache 1333 MHz 130 w (with fan) -

81Y6555 A0ZV Intel Xeon X5687 4C 3.60 GHz 12 MB Cache 1333 MHz 130w (with fan) -

81Y6556 A0ZW Intel Xeon X5690 6C 3.46 GHz 12 MB Cache 1333 MHz 130w (with fan) 82x

Questions and Answers:

Need help?

Do you have a question about the IBM System x3550 M3 and is the answer not in the manual?

IBM System x3550 M3 Specifications

General

Tcase	77.6 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBV4
Processor cache	12 MB
Processor cores	4
Processor model	E5620
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Westmere EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	18
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1, 10
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	-
Total storage capacity	0 GB
Maximum storage capacity	8 TB
Number of HDDs installed	0
Internal memory	24 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	6 x 4 GB
Maximum graphics card memory	16 MB
Graphics card family	Matrox
Graphics card memory type	GDDR2
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Power supply	460 W
Power supply type	AC
Power requirements	100 - 240 V
Power supply input frequency	50 - 60 Hz
Compatible operating systems	Microsoft Windows Server 2008 R2 and 2008, Red Hat Enterprise Linux, SUSE Linux Enterprise Server and VMware ESXi, Oracle Solaris 10 (model dependent)
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	8 - 80 %
Chassis type	Rack (1U)
Processor ARK ID	47925
Intel® Turbo Boost Technology	1.0
