IBM System x3550 M3 36
Top-of-rack Ethernet switches
The server supports the top-of-rack Ethernet switches from IBM System Networking listed in the following
table.
Table 24. IBM System Networking - Top-of-rack switches
Part number Description
IBM System Networking - 1 Gb top-of-rack switches
0446013 IBM System Networking RackSwitch G8000R
7309CFC IBM System Networking RackSwitch G8000F
7309CD8 IBM System Networking RackSwitch G8000DC
7309G52 IBM System Networking RackSwitch G8052R
730952F IBM System Networking RackSwitch G8052F
427348E IBM Ethernet Switch J48E
6630010 Juniper Networks EX2200 24 Port
6630011 Juniper Networks EX2200 24 Port with PoE
6630012 Juniper Networks EX2200 48 Port
6630013 Juniper Networks EX2200 48 Port with PoE
IBM System Networking - 10 Gb top-of-rack switches
7309DRX IBM System Networking RackSwitch G8264CS (Rear to Front)
7309DFX IBM System Networking RackSwitch G8264CS (Front to Rear)
7309BD5 IBM System Networking RackSwitch G8124DC
7309BR6 IBM System Networking RackSwitch G8124ER
7309BF7 IBM System Networking RackSwitch G8124EF
7309G64 IBM System Networking RackSwitch G8264R
730964F IBM System Networking RackSwitch G8264F
7309CR9 IBM System Networking RackSwitch G8264TR
7309CF9 IBM System Networking RackSwitch G8264TF
0719410 Juniper Networks EX4500 - Front to Back Airflow
0719420 Juniper Networks EX4500 - Back to Front Airflow
IBM System Networking - 40 Gb top-of-rack switches
8036ARX IBM System Networking RackSwitch G8316R
8036AFX IBM System Networking RackSwitch G8316F
For more information, see the list of IBM Redbooks Product Guides in the Top-of-rack switches category:
http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=tor

IBM System x3550 M3 Specifications

General

Tcase	77.6 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBV4
Processor cache	12 MB
Processor cores	4
Processor model	E5620
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Westmere EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	18
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1, 10
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	-
Total storage capacity	0 GB
Maximum storage capacity	8 TB
Number of HDDs installed	0
Internal memory	24 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	6 x 4 GB
Maximum graphics card memory	16 MB
Graphics card family	Matrox
Graphics card memory type	GDDR2
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Power supply	460 W
Power supply type	AC
Power requirements	100 - 240 V
Power supply input frequency	50 - 60 Hz
Compatible operating systems	Microsoft Windows Server 2008 R2 and 2008, Red Hat Enterprise Linux, SUSE Linux Enterprise Server and VMware ESXi, Oracle Solaris 10 (model dependent)
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	8 - 80 %
Chassis type	Rack (1U)
Processor ARK ID	47925
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	711 mm
Width	440 mm
Height	43 mm
Weight	15600 g
