IBM System x3550 M3 35
Table 23. External tape options (Part 2)
Part number Description
External backup units*
362516X IBM RDX Removable Hard Disk Storage System - External USB 160 GB Bundle
362532X IBM RDX Removable Hard Disk Storage System - External USB 320 GB Bundle
362550X IBM RDX Removable Hard Disk Storage System - External USB 500 GB Bundle
3628L3X IBM Half High LTO Gen 3 External SAS Tape Drive (with US line cord)
3628L4X IBM Half High LTO Gen 4 External SAS Tape Drive (with US line cord)
3628L5X IBM Half High LTO Gen 5 External SAS Tape Drive (with US line cord)
3628N3X IBM Half High LTO Gen 3 External SAS Tape Drive (without line cord)
3628N4X IBM Half High LTO Gen 4 External SAS Tape Drive (without line cord)
3628N5X IBM Half High LTO Gen 5 External SAS Tape Drive (without line cord)
3580S3V System Storage TS2230 Tape Drive Express Model H3V
3580S4V System Storage TS2240 Tape Drive Express Model H4V
3580S5E System Storage TS2250 Tape Drive Express Model H5S
3580S5X System Storage TS2350 Tape Drive Express Model S53
3572S4R TS2900 Tape Library with LTO4 HH SAS drive & rack mount kit
3572S5R TS2900 Tape Library with LTO5 HH SAS drive & rack mount kit
35732UL TS3100 Tape Library Model L2U Driveless
35734UL TS3200 Tape Library Model L4U Driveless
46X2682† LTO Ultrium 5 Fibre Channel Drive
46X2683† LTO Ultrium 5 SAS Drive Sled
46X2684† LTO Ultrium 5 Half High Fibre Drive Sled
46X2685† LTO Ultrium 5 Half High SAS Drive Sled
46X6912† LTO Ultrium 4 Half High Fibre Channel Drive Sled
46X7117† LTO Ultrium 4 Half High SAS DriveV2 Sled
46X7122† LTO Ultrium 3 Half High SAS DriveV2 Sled
* Note: The external tape drives listed can be ordered through System x sales channel. Server may support other
IBM tape drives that are not listed in this table. Refer to IBM System Storage Interoperability Center for further
information.
† Note: These part numbers are the tape drives options for 35732UL and 35734UL.
For more information, see the list of IBM Redbooks Product Guides in the Backup units category:
http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=tape

IBM System x3550 M3 Specifications

General

Tcase	77.6 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBV4
Processor cache	12 MB
Processor cores	4
Processor model	E5620
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Westmere EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	18
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1, 10
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	-
Total storage capacity	0 GB
Maximum storage capacity	8 TB
Number of HDDs installed	0
Internal memory	24 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	6 x 4 GB
Maximum graphics card memory	16 MB
Graphics card family	Matrox
Graphics card memory type	GDDR2
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Power supply	460 W
Power supply type	AC
Power requirements	100 - 240 V
Power supply input frequency	50 - 60 Hz
Compatible operating systems	Microsoft Windows Server 2008 R2 and 2008, Red Hat Enterprise Linux, SUSE Linux Enterprise Server and VMware ESXi, Oracle Solaris 10 (model dependent)
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	8 - 80 %
Chassis type	Rack (1U)
Processor ARK ID	47925
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	711 mm
Width	440 mm
Height	43 mm
Weight	15600 g
