Integrated virtualization
The server supports VMware ESXi installed on a USB memory key. The key is installed in a USB socket
inside the server. The following table lists the virtualization options.
Table 15. Virtualization options
Part
number
Feature
code
Description Maximum
supported
41Y8278 1776 IBM USB Memory Key for VMware ESXi 4 1
41Y8287 3033 IBM USB Memory Key for VMware ESXi 4.1 1
41Y8296 A1NP IBM USB Memory Key for VMware ESXi 4.1 Update 1 1
41Y8300 A2VC IBM USB Memory Key for VMware ESXi 5.0 1
41Y8307 A383 IBM USB Memory Key for VMware ESXi 5.0 Update 1 1
41Y8311 A2R3 IBM USB Memory Key for VMware ESXi 5.1 1
41Y8298 A2G0 IBM Blank USB Memory Key for VMware ESXi Downloads 1
Remote management
The server contains IBM Integrated Management Module (IMM), which provides advanced
service-processor control, monitoring, and an alerting function. If an environmental condition exceeds a
threshold or if a system component fails, the IMM lights LEDs to help you diagnose the problem, records
the error in the event log, and alerts you to the problem. Optionally, the IMM also provides a virtual
presence capability for remote server management capabilities.
The IMM provides remote server management through industry-standard interfaces:
Intelligent Platform Management Interface (IPMI) Version 2.0

Simple Network Management Protocol (SNMP) Version 3

Common Information Model (CIM)

Web browser

The optional virtual media key is required to enable the remote presence and blue-screen capture
features. The remote presence feature provides the following functions:
Remotely viewing video with graphics resolutions up to 1280x1024 at 75 Hz

Remotely accessing the server, using the keyboard and mouse from a remote client

Mapping the CD or DVD drive, diskette drive, and USB flash drive on a remote client, and mapping

ISO and diskette image files as virtual drives that are available for use by the server
Uploading a diskette image to the IMM memory and mapping it to the server as a virtual drive

The blue-screen capture feature captures the video display contents before the IMM restarts the server
when the IMM detects an operating-system hang condition. A system administrator can use the
blue-screen capture to assist in determining the cause of the hang condition. The following table lists the
remote management option.
Table 16. Remote management option
Part
number
Feature
code
Description Maximum
supported
46C7526 5080 IBM Virtual Media Key 1

IBM System x3550 M3 Specifications

General

Tcase	77.6 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBV4
Processor cache	12 MB
Processor cores	4
Processor model	E5620
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Westmere EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	18
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1, 10
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	-
Total storage capacity	0 GB
Maximum storage capacity	8 TB
Number of HDDs installed	0
Internal memory	24 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	6 x 4 GB
Maximum graphics card memory	16 MB
Graphics card family	Matrox
Graphics card memory type	GDDR2
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Power supply	460 W
Power supply type	AC
Power requirements	100 - 240 V
Power supply input frequency	50 - 60 Hz
Compatible operating systems	Microsoft Windows Server 2008 R2 and 2008, Red Hat Enterprise Linux, SUSE Linux Enterprise Server and VMware ESXi, Oracle Solaris 10 (model dependent)
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	8 - 80 %
Chassis type	Rack (1U)
Processor ARK ID	47925
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	711 mm
Width	440 mm
Height	43 mm
Weight	15600 g
