IBM System x3550 M3 23

The following table lists additional supported network adapters.

Table 11. Network adapters

Part

number

Feature

code

Description Maximum

supported

40 Gb Ethernet

00D9550 A3PN Mellanox ConnectX-3 FDR VPI IB/E Adapter for IBM System x 2

10 Gb Ethernet

42C1820 1637 Brocade 10Gb CNA for IBM System x 2

49Y7910 A18Y Broadcom NetXtreme II Dual Port 10GBaseT Adapter for IBM System x 2

49Y4250 5749 Emulex 10GbE Virtual Fabric Adapter for IBM System x 2

49Y7950 A18Z Emulex 10GbE Virtual Fabric Adapter II for IBM System x 2

95Y3751 A348 Emulex Dual Port VFAII Adapter & FCoE/iSCSI License for IBM System x 2

49Y7960 A2EC Intel x520 Dual Port 10GbE SFP+ Adapter for IBM System x 2

49Y7970 A2ED Intel X540-T2 Dual Port 10GBaseT Adapter for IBM System x 2

81Y9990 A1M4 Mellanox ConnectX-2 Dual Port 10GbE Adapter for IBM System x 2

00D9690 A3PM Mellanox ConnectX-3 10 GbE Adapter for IBM System x 2

42C1800 5751 QLogic 10Gb CNA for IBM System x 2

1 Gb Ethernet

90Y9370 A2V4 Broadcom NetXtreme I Dual Port GbE Adapter for IBM System x 2

90Y9352 A2V3 Broadcom NetXtreme I Quad Port GbE Adapter for IBM System x 2

46M1076 3585 Dual port 1Gb Ethernet Daughter Card 2

49Y4230 5767 Intel Ethernet Dual Port Server Adapter I340-T2 for IBM System x 2

49Y4240 5768 Intel Ethernet Quad Port Server Adapter I340-T4 for IBM System x 2

42C1780 2995 NetXtreme II 1000 Express Dual Port Ethernet Adapter 2

42C1750 2975 PRO/1000 PF Server Adapter 2

39Y6126 2944 PRO/1000 PT Dual Port Server Adapter by Intel 2

39Y6136 2974 PRO/1000 PT Quad Port Server Adapter 2

InfiniBand

00D9550 A3PN Mellanox ConnectX-3 FDR VPI IB/E Adapter for IBM System x 2

95Y3750 A2MY Mellanox ConnectX-2 Dual-port QSFP QDR IB Adapter for IBM System x 1

For more information, see the list of IBM Redbooks Product Guides in the Networking adapters category:

http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=networkadapters

Questions and Answers:

Need help?

Do you have a question about the IBM System x3550 M3 and is the answer not in the manual?

IBM System x3550 M3 Specifications

General

Tcase	77.6 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBV4
Processor cache	12 MB
Processor cores	4
Processor model	E5620
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Westmere EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	18
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1, 10
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	-
Total storage capacity	0 GB
Maximum storage capacity	8 TB
Number of HDDs installed	0
Internal memory	24 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	6 x 4 GB
Maximum graphics card memory	16 MB
Graphics card family	Matrox
Graphics card memory type	GDDR2
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Power supply	460 W
Power supply type	AC
Power requirements	100 - 240 V
Power supply input frequency	50 - 60 Hz
Compatible operating systems	Microsoft Windows Server 2008 R2 and 2008, Red Hat Enterprise Linux, SUSE Linux Enterprise Server and VMware ESXi, Oracle Solaris 10 (model dependent)
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	8 - 80 %
Chassis type	Rack (1U)
Processor ARK ID	47925
Intel® Turbo Boost Technology	1.0
