IBM System x3550 M3 31
The RAID controllers listed in the following table are supported and connect to external expansion
enclosures.
Table 19. RAID controllers for external storage expansion enclosures
Part number Feature
code
Description Maximum
supported
46M0830 0094 ServeRAID M5025 SAS/SATA Controller 1
46M0930 5106 ServeRAID M5000 Series Advance Feature Key* 1 per one M5025
81Y4426 A10C ServeRAID M5000 Series Performance Accelerator Key* 1 per one M5025
* Note: The Advanced Feature Key and Performance Accelerator Key cannot be used at the same time. Only one
key can be installed onto the RAID controller.
The ServeRAID M5025 SAS/SATA Controller has the following specifications:
Two Mini-SAS external connectors

Supports RAID levels 0, 1, 5, 10, and 50

Supports RAID 6 and 60 with the optional M5000 Advanced Feature Key

Performance optimization for SSD drives with optional M5000 Series Performance Accelerator Key

6 Gbps throughput per port

PCI Express 2.0 x8 host interface

Based on the LSI SAS2108 6 Gbps ROC controller

512 MB of onboard cache

Intelligent Li-Ion-based battery backup unit with up to 48 hours of data retention

Supports connectivity to the EXP3000, EXP2512, and EXP2524 storage expansion enclosures

For more information about the M5025, see the ServeRAID M5025 SAS/SATA Controller for IBM System
x Product Guide: http://www.redbooks.ibm.com/abstracts/tips0739.html?Open

IBM System x3550 M3 Specifications

General

Tcase	77.6 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBV4
Processor cache	12 MB
Processor cores	4
Processor model	E5620
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Westmere EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	18
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1, 10
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	-
Total storage capacity	0 GB
Maximum storage capacity	8 TB
Number of HDDs installed	0
Internal memory	24 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	6 x 4 GB
Maximum graphics card memory	16 MB
Graphics card family	Matrox
Graphics card memory type	GDDR2
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Power supply	460 W
Power supply type	AC
Power requirements	100 - 240 V
Power supply input frequency	50 - 60 Hz
Compatible operating systems	Microsoft Windows Server 2008 R2 and 2008, Red Hat Enterprise Linux, SUSE Linux Enterprise Server and VMware ESXi, Oracle Solaris 10 (model dependent)
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	8 - 80 %
Chassis type	Rack (1U)
Processor ARK ID	47925
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	711 mm
Width	440 mm
Height	43 mm
Weight	15600 g
