Storage host bus adapters
The following table lists the storage HBAs that are supported by the x3650 M4 HD server. The maximum
quantity that is listed is for configurations with two processors installed. If one processor is installed, the
maximum quantity that is supported is half of the listed value.
Table 14. Storage adapters
Part number Feature
code
Description Maximum
supported
Fibre Channel - 16 Gb
81Y1668 A2XU Brocade 16Gb FC Single-port HBA for IBM System x 6
81Y1675 A2XV Brocade 16Gb FC Dual-port HBA for IBM System x 6
81Y1655 A2W5 Emulex 16Gb FC Single-port HBA for IBM System x 6
81Y1662 A2W6 Emulex 16Gb FC Dual-port HBA for IBM System x 6
00Y3337 A3KW QLogic 16Gb FC Single-port HBA for IBM System x 6
00Y3341 A3KX QLogic 16Gb FC Dual-port HBA for IBM System x 6
Fibre Channel - 8 Gb
46M6049 3589 Brocade 8 Gb FC Single-port HBA for IBM System x 6
46M6050 3591 Brocade 8 Gb FC Dual-port HBA for IBM System x 6
42D0485 3580 Emulex 8 Gb FC Single-port HBA for IBM System x 6
42D0494 3581 Emulex 8 Gb FC Dual-port HBA for IBM System x 6
42D0501 3578 QLogic 8 Gb FC Single-port HBA for IBM System x 6
42D0510 3579 QLogic 8 Gb FC Dual-port HBA for IBM System x 6
For more information, see the list of IBM Redbooks Product Guides in the Host bus adapters category:
http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=hba

IBM System x3650 M4 HD Specifications

General

Memory Slots	24 DIMM slots
Form Factor	2U rack
Chipset	Intel C600 series
Expansion Slots	Up to six PCIe 3.0 slots
Processor	Intel Xeon E5-2600 v2 product family
Memory	Up to 768 GB
Storage	Hot-swap SAS/SATA/SSD
Storage Capacity	Up to 16 TB
RAID Support	RAID 0, 1, 10
Power Supply	Dual 750W or 900W hot-swap power supplies
Network Interface	Four integrated Gigabit Ethernet ports
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
