IBM System x3650 M4 HD 41
Rack cabinets
The server supports the rack cabinets that are listed in the following table.
Table 28. Rack cabinets
Part number Description
201886X IBM 11U Office Enablement Kit
93072PX IBM 25U Static S2 Standard Rack
93072RX IBM 25U Standard Rack
93074RX IBM 42U Standard Rack
93074XX IBM 42U Standard Rack Extension
93084EX IBM 42U Enterprise Expansion Rack
93084PX IBM 42U Enterprise Rack
93604EX IBM 42U 1200 mm Deep Dynamic Expansion Rack
93604PX IBM 42U 1200 mm Deep Dynamic Rack
93614EX IBM 42U 1200 mm Deep Static Expansion Rack
93614PX IBM 42U 1200 mm Deep Static Rack
93624EX IBM 47U 1200 mm Deep Static Expansion Rack
93624PX IBM 47U 1200 mm Deep Static Rack
99564RX IBM S2 42U Dynamic Standard Rack
99564XX IBM S2 42U Dynamic Standard Expansion Rack
For more information, see the list of IBM Redbooks Product Guides in the Rack cabinets and options
category:
http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=rack

IBM System x3650 M4 HD Specifications

General

Memory Slots	24 DIMM slots
Form Factor	2U rack
Chipset	Intel C600 series
Expansion Slots	Up to six PCIe 3.0 slots
Processor	Intel Xeon E5-2600 v2 product family
Memory	Up to 768 GB
Storage	Hot-swap SAS/SATA/SSD
Storage Capacity	Up to 16 TB
RAID Support	RAID 0, 1, 10
Power Supply	Dual 750W or 900W hot-swap power supplies
Network Interface	Four integrated Gigabit Ethernet ports
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
