Local server management
The x3650 M4 HD offers local console access USB ports and a video port on the rear of the server, as
shown in Figure 3. Console access from the front of the server is available through an optional console
breakout cable that is connected to a port on the front of the server as shown in the following figure.
Figure 8. Optional console breakout cable
The console breakout cable can be ordered by using the information in the following table.
Table 20. Console breakout cable
Part number Feature
code
Description Maximum
supported
Standard
models
where used
00Y8325 A47X IBM x3650 M4 HD Video and USB Breakout Cable 1 None

IBM System x3650 M4 HD Specifications

General

Memory Slots	24 DIMM slots
Form Factor	2U rack
Chipset	Intel C600 series
Expansion Slots	Up to six PCIe 3.0 slots
Processor	Intel Xeon E5-2600 v2 product family
Memory	Up to 768 GB
Storage	Hot-swap SAS/SATA/SSD
Storage Capacity	Up to 16 TB
RAID Support	RAID 0, 1, 10
Power Supply	Dual 750W or 900W hot-swap power supplies
Network Interface	Four integrated Gigabit Ethernet ports
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
