IBM System x3650 M4 HD 9
Express models
The following table lists the express models.
Table 3. Express models
Model Intel Xeon processors†
(two maximum)
Memory RAID
controller
Disk
bays
Disks Slots*
S/A/
M
GbE Power
North America (NA)
5460-EAU 1x E5-2640 v2 8C 2.0GHz
20MB 1600MHz 95W
1x 8 GB
1600 MHz
M5210-e 16x 2.5" 4x 1TB
NL SAS
3 / 3 /
6
4 1x 750W
Latin America (LA)
5460-EAU 1x E5-2640 v2 8C 2.0GHz
20MB 1600MHz 95W
1x 8 GB
1600 MHz
M5210-e 16x 2.5" 4x 1TB
NL SAS
3 / 3 /
6
4 1x 750W
Europe Integrated Operating Team (IOT)
5460-E1G 1x E5-2620 v2 6C 2.1GHz
15MB 1600MHz 80W
1x 8 GB
1600 MHz
M5210-e
+ 1GB Flash/R5
16x 2.5" Open 3 / 3 /
6
4 1x 750W
Central and Eastern Europe (CEE) and Middle East and Africa (MEA)
5460-E1G 1x E5-2620 v2 6C 2.1GHz
15MB 1600MHz 80W
1x 8 GB
1600 MHz
M5210-e
+ 1GB Flash/R5
16x 2.5" Open 3 / 3 /
6
4 1x 750W
Russia/Commonwealth of Independent States (CIS)
5460-E1G 1x E5-2620 v2 6C 2.1GHz
15MB 1600MHz 80W
1x 8 GB
1600 MHz
M5210-e
+ 1GB Flash/R5
16x 2.5" Open 3 / 3 /
6
4 1x 750W
Japan
5460-PAA 1x E5-2603 v2 4C 1.8GHz
10MB 1333MHz 80W
1x 8 GB
(1333
MHz)‡
M5210-e
+ 1GB Flash/R5
16x 2.5" Open 3 / 3 /
6
4 1x 750W
† Processor detail: Processor quantity and model, cores, core speed, L3 cache, memory speed, power
consumption.
* The PCIe slot counts are: Slots standard / slots available / slots maximum.
‡ Model PAA includes a 1600 MHz DIMM standard, however, it operates at 1333 MHz to match the installed
processor.

IBM System x3650 M4 HD Specifications

General

Memory Slots	24 DIMM slots
Form Factor	2U rack
Chipset	Intel C600 series
Expansion Slots	Up to six PCIe 3.0 slots
Processor	Intel Xeon E5-2600 v2 product family
Memory	Up to 768 GB
Storage	Hot-swap SAS/SATA/SSD
Storage Capacity	Up to 16 TB
RAID Support	RAID 0, 1, 10
Power Supply	Dual 750W or 900W hot-swap power supplies
Network Interface	Four integrated Gigabit Ethernet ports
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
