When replacing: When replacing the hinge covers
removed in step .5/, attach them to the shield
sheet with double-sided adhesive tape as the old
ones had been attached.
Step Size (Quantity) Torque
.1/ (a) M 2.5 x 6mm, nylon-coated (2) 3-4 kgcm
(b) M 2.5 x 6mm, special-head (1) 3-3.5 kgcm
.2/ M 2.5 x 6mm, nylon-coated (2) 3-4 kgcm
Note: Make sure you use the correct screw, and tighten all
screws firmly to the torque shown in the table if you have a
torque screwdriver. Never use a screw that you removed.
Use a new one. Make sure the screws are tightened
firmly.
100 IBM ThinkPad 380XD, 385XD
