1090 Fan Assembly, CPU Card,
Thermal Rubber
Battery Pack (1020)
Keyboard Unit (1040)
CD-ROM and Diskette Drive Assembly (1060)
LCD Unit (1080)
Attention:
When removing, be careful not to damage the CPU
card.
Step Size (Quantity) Torque
.1/ M 2 x 6 mm, nylon-coated (2) 2-3 kgcm
.3/ M 2 x 18 mm, nylon-coated (3) 2-3 kgcm
Note: Make sure you use the correct screw, and tighten all
screws firmly to the torque shown in the table if you have a
torque screwdriver. Never use a screw that you removed.
Use a new one. Make sure the screws are tightened
firmly.
IBM ThinkPad 380XD, 385XD (2635) 79
