1060 CD-ROM Drive and Diskette Drive
Assembly
Battery Pack (1020)
Keyboard Unit (1040)
Note: Be careful that the computer does not fall backward
when you remove the CD-ROM and diskette drive
assembly.
Step Size (Quantity) Torque
.1/ M 2.5 x 6 mm, nylon-coated (1) 3-4 kgcm
.2/ M 2.5 x 6 mm, nylon-coated (1) 3-4 kgcm
.4/ M 2.5 x 8 mm, nylon-coated (2) 3-4 kgcm
.5/ M 2.5 x 6 mm, nylon-coated (1) 3-4 kgcm
Note: Make sure you use the correct screw, and tighten all
screws firmly to the torque shown in the table if you have a
torque screwdriver. Never use a screw that you removed.
Use a new one. Make sure the screws are tightened
firmly.
IBM ThinkPad 380XD, 385XD (2635) 71
