1110 Box Speaker and Microphone
Battery Pack (1020)
Keyboard Unit (1040)
CD-ROM and Diskette Drive Assembly (1060)
LCD Unit (1080)
Upper Shield Case (1100)
Step Size (Quantity) Torque
.1/ M 2.5 x 12 mm, nylon-coated (3) 3-4 kgcm
Note: Make sure you use the correct screw, and tighten all
screws firmly to the torque shown in the table if you have a
torque screwdriver. Never use a screw that you removed.
Use a new one. Make sure the screws are tightened
firmly.
IBM ThinkPad 380XD, 385XD (2635) 83
