1100 Upper Shield Case
Battery Pack (1020)
Keyboard Unit (1040)
CD-ROM/Diskette Drive Assembly (1060)
LCD Unit (1080)
Step Size (Quantity) Torque
.2/ M 2.5 x 8 mm, nylon-coated (2) 3-4 kgcm
.3/ M 2.5 x 6 mm, nylon-coated (3) 3-4 kgcm
.4/ M 2.5 x 6 mm, bighead (1) 3-4 kgcm
Note: Make sure you use the correct screw, and tighten all
screws firmly to the torque shown in the table if you have a
torque screwdriver. Never use a screw that you removed.
Use a new one. Make sure the screws are tightened
firmly.
82 IBM ThinkPad 380XD, 385XD
