1120 PCMCIA Slot
Battery Pack (1010)
DIMM Cover (1020)
Keyboard Unit (1030)
CD-ROM/FDD Assembly (1040)
LCD Unit (1070)
Hard Disk Drive (1060)
System Board Assembly (1080)
Upper Shield Case (1090)
Lower Shield Case (1110)
Step Size (Quantity) Torque
.1/ M 2 x 16mm (2) 2 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
ThinkPad 380, 385 (2635) 87
