2020 LCD Panel
 Battery Pack (1030)
 Keyboard Unit (1050)
 LCD Assembly (1060)
 LCD Front Cover (2010)
DSTN Panel
When Replacing:
Connect the LCD connector to the inverter card by
lining them up straight:
Step Size (Quantity) Torque
.1/ M 2.5 x 6 mm, flathead (4) 3.0 kgcm
Note: Make sure you use the correct screw and tighten it to
the torque specified. Do not use the screw that you removed,
use a new screw.
ThinkPad 560, 560E (2640) 175
