3020 ThinkPad Dock top cover
Note
This section is only for the ThinkPad Dock (FRU no.
08N1546). The top cover and screw kit for ThinkPad
Dock (FRU no. 12P4143) is not available for the
ThinkPad Dock with extension plate (FRU no.
08N1537) .
1
(Rear view)
Step Screw (quantity) Torque
1 M2.5 × 4.8 mm (2) 0.392 Nm
(4 kgfcm)
(continued)
Removing and replacing a FRU
ThinkPad T20, T21, T22 and T23 series 135
