IBM ThinkPad T21

6
aa
5
4
Step Screw (quantity) Torque
4 M2.5 × 4.8 mm, nylon-coated (1) 0.392 Nm
(4 kgfcm)
When installing:
1. Install the hinge cover according to the step 5, 6
and then tighten the screw 4. In step 5, take care
not to damage the lens.
2. Make sure that both latches a are firmly attached
and snap into place.
Removing and replacing a FRU
86 ThinkPad T20, T21, T22, T23 (MT 2647/2648)
