1150 Speaker
For access, remove these FRUs, in order:
v 1010 Battery pack on page 58
v 1020 Backup battery on page 59
v 1030 Hard-disk drive on page 61
v 1070 Ultrabay 2000 device on page 71
v 1080 Keyboard on page 72
v 1090 Keyboard CRU insulator on page 80
v 1100 Hinge cover on page 81
v 1110 Keyboard bezel on page 86
1
2
Step Screw (quantity) Torque
1 M2.5 × 14 mm, nylon-coated (2) 39.2 Ncm
(4 kgfcm)
Removing and replacing a FRU
102 ThinkPad T20, T21, T22, T23 (MT 2647/2648)
