Miscellaneous parts
Italicized letters in parentheses are reference to the
exploded view on page 146 and 151.
FRU P/N
Screw kit for T20, T21, T22 and T23 series
Screw kit (including nylon-coated screws):
v M2.5 x 14 mm, bind head (15)
v M2.5 x 11.5 mm, flat head (5)
v M2.5 x 4.8 mm, flat head (20)
v M2.5 x 3.5 mm, flat head (10)
v M2.0 x 13.5 mm, pan head (15)
v M2..0 x 4.0 mm, small head (10)
v Hex stud D-sub (10)
v Coin screw (1)
v Security screw (1)
v Blank cap, enhanced port (5)
v Screw caps, rear (5)
v Screw caps (5)
v Screw caps (painted) (10)
v Screw caps (not painted, thin) (10)
v Screw caps (not painted) (5)
26P9654
Common miscellaneous parts for T20, T21 and T22 series
System board miscellaneous parts:
v System board stud
v Insulator, PC card
v Insulator, battery latch
v Keyboard connector guide
v Shock rubber
v Insulator, docking connector
v Insulator, fan connector
v Insulator, Ultrabay 2000 connector
v Insulator, I/O connector
v Shield, Mini PCI
v Insulator, hard-disk drive
v Screw caps
v Screw caps, rear
08K7099
I/O card miscellaneous parts:
v DC jack connector
v Cable RJ11/45 to mini PCI
v Insulator, modular jack
v Insulation tape
v Screw caps
v Screw caps, rear
08K6683
(continued)
Parts list
ThinkPad T20, T21, T22 and T23 series 161
